USB3.0 Digital HDMI Output Camera With Gigabit Network Interface

Brand Name : Phidix

Model Number : M21137

Certification : IATF16949，CE

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 1000 PCS/Month

Delivery Time : 15-20 Work Days

Packaging Details : 1 PC/Carton

Customization : OEM, ODM

Packing : 1 PC/Carton

Warranty : 1 year

Lead-time : 15-20 Work Days

Theory : Industrial Camera

Target : 1/1.8

Output Mode : HDMI, Gigabit，USB3.0x2

Frame Rate : 60FPS

Resolution : 3840 x 2160

Contact Now

60FPS Digital Camera with HDMI USB3.0X2 Gigabit Network Interface

M21137 60FPS Digital Camera with HDMI USB3.0X2 Gigabit Network Interface. This series digital camera is specially designed with HDMI, USB3.0x2, Gigabit network interface, SONY 8 million high-performance photosensitive chips, HDR wide dynamic, automatic edge patrol, automatic exposure and other functions.

Features:

  • Independent adjustment of image color and strong light suppression;
  • The image has true color, low noise and high sensitivity.
  • HDMI interface adapts to 4K and 2K mode switching;
  • Support 4K60 frame and 1080p60 frame plotting;
  • The network port transmits images in real time and interacts in real time;
  • Custom interface editing and custom template editing functions;
  • Image saving supports JPG and BMP formats;
  • Support 4k and 1080p video recording;
  • Dual USB3.0, Gigabit multi-choice interface,
  • The fan can be controlled to turn on and off;
  • The latest image measurement system can export EXCEL data;
  • Increase magnification display function, real-time magnification feedback and screen size feedback.

Item Description / Value M21137
Maximum Resolution: 3840 X 2160 ●
Pixel size: 2.0μmx2.0μm ●
Target: 1/1.8 ●
Data: 12bit ●
Exposure: Line by line ●
Color Output: Colorful ●
FPS Output: 60FPS ●
Processor: ARM Cortex A53, 4-Core@Max.1 .4GHz Main Processor ●
Operation System: Measurement system independently developed based on Linux3.1 ●
Interface: HDMI,USB3.0X2,Gigabit network ●
Power Supply: DC-12V/1A ●

Remarks: ● means standard configuration ○ means optional

USB3.0 Digital HDMI Output Camera With Gigabit Network Interface

USB3.0 Digital HDMI Output Camera With Gigabit Network Interface

USB3.0 Digital HDMI Output Camera With Gigabit Network Interface

USB3.0 Digital HDMI Output Camera With Gigabit Network Interface
